Signal Conditioners
5073B, Industrial Charge Amplifier For 1 To 4 Channels, 卤10 V / 4鈥20 MA
The industrial charge amplifier for multi-purpose (ICAM-B) can be used wherever mechanical quantities are measured with piezoelectric sensors. Piezoelectric sensors produce an electric charge which varies in direct proportion to the load acting on the sensor.
The charge amplifier Type 5073B… converts a charge signal into a low-impedance voltage signal. It covers slow, quasi-static signals as well as dynamic processes. Depending on its variant, up to four sensors can be connected at the same time.
5073B
The industrial charge amplifiers for piezoelectric sensors allow reliable and precise capture of dynamic and quasi-static processes in more harsh environments.
Highlights
- Wide adjustable measurement range: ±20 … ±1000000 pC
- 1, 2, 3 or 4 channels with individual configuration and control
- Output signal: ±10 V or 4 … 20 mA with up to 20 kHz bandwidth
- Web user-interface for device configuration
- Digital data streaming up to 1 kSps
- Virtual channels for real-time calculations using one or more sensor channels
- Features: peak and integral, RMS values, low-pass filter and switchable high-pass filter
